The heat exchanger is a piece of equipment built for efficient heat transfer from one medium to another. The media may be separated by a solid wall to prevent mixing or they may be in direct contact.Wuhan XinFa Petrochemical Equipment Co., Ltd is the main pressure vessel manufacturer in China, it's one of the largest heat ex-changer and storage tank provider for the petrochemical industry.

20000m³ gas tank

gas liquid tank design

gas liquid tank

gas tank design

helical baffles heat exchanger design

helical baffles heat exchangers

helical baffles heat exchangers

helical baffles heat exchangers

helical baffles heat ex-changer: fluid flow spiral forward in Shells
the flow resistance is smaller than ordinary baffles heat changing efficiency is higher. Optimized heat ex-changer design enable reliable production, easy cleaning and energy efficient operation and are vital to supply safe and competitive products.

methanol storage tank design

methanol storage tank

Heat exchanger manufacturer

The heat exchanger belongs to one of the 4 kind of pressure vessels according to its manufacture process.Wuhan XinFa Petrochemical Equipment Co., Ltd designs and manufactures different kind of hear exchanger such as floating-head type heat exchanger, fixed tube-sheet heat exchanger, U-tube type heat exchanger and helical baffles heat exchangers.

fixed tube-sheet heat exchanger draft

fixed tube-sheet heat exchanger

fixed tube-sheet heat exchanger 2

fixed tube-sheet heat exchanger:
the structure is sample,and lowly cost,it is used for shell side  not serious or chemical cleaning occasions, when it is expaned bigger in thermal, it can be  set expansion joint in shell.

floating-head type heat exchanger:
the structure is complex,the one tube-sheet is fixed,and the another tube-sheet can float freely,the floating-head  removable pipe bundles can insert easily or it can be repair and clean.

U-tube type heat exchanger：
it is only one tube-sheet,low cost,tube-bundles clean easily,it is difficult to clean inside tube-bundles,can't exchange heat exchanger inside tube-bundles

floating-head type heat exchanger draft

floating-head type heat exchanger



floating-head



heat exchanger

U shape tube

U-tube type heat exchanger draft

U-tube type heat exchanger

You are welcome to send quote to alexshawn1216@gmail.com if you need info about the heat exchanger.

pressure vessel for oil refining papermaking power and metallurgy

The pressure vessel are widely used in oil refinery, papermaking, power generation and metallurgy industry, Wuhan XinFa Petrochemical Equipment Co., Ltd designs and manufactures pressure vessels for the industry clients.

Our oil and gas pressure vessels can be constructed with a range of capacity, material and wall thickness options, and is certified in accordance with the ASME Boiler and Pressure Vessel Code, Section VIII, Division 1. In addition, NRG’s state-of-the-art facility operates under strict API, ISO and HSE guidelines, so our quality control processes ensure that each product operates efficiently, safely and durably.

Heat exchanger

corrosion protection of heat exchangers in refinery

marine desalination equipment

Oil gas tank

Pressure vessels

Pressure vessels for oil refining papermaking power generation and metallurgy

Wuhan XinFa Petrochemical Equipment Co., Ltd has the experience to engineer, design, assemble and install the high-quality, conforming pressure vessels you need for project productivity and crew safety.  We’re committed to providing you with equipment that is durable, economical and long-lasting, and our engineering experts are ready to meet your application requirements while ensuring performance and safety. The pressure vessels such as gas tank, oil tank, cooler, reactor, heat exchanger, steam condenser,  towers are designed and manufactured are widely used for oil refining, paper making, power generation, metallurgy, medicine and other industry.

There are the pressure vessel equipped for oil refining,  paper making, power generation industry.

Cooler

100 m3 natural gas storage tank

stainless steel heat exchanger

underground storage gasoline tank

Paper mills spewing out storehouse

Reactor

Power plant steam condenser

Food industry towers

The pressure vessels designed and manufactured by our company continually to prove their value oil & gas, chemical & petrochemical, refining, industrial, and construction. We've built an extensive quality-control system ensures that all customers needs have been carefully served with properly designed, constructed, inspected per ASME and the required specifications.

coking/delayed coking butyl-octyl alcohol pressure vessel tower manufacturing

Delayed coking unit consists of eight components: (1) coking, mainly equipment is furmace and coke towers. it contains single furnace double towers, two furnace four towers, also have a direct jointly with other devices. (2) fractionation, mainly equipment is fractionator. (3) coking gas recovery and desulfurization, mainly equipment is absorb desorption tower, stabilizer tower , Reabsorption Tower etc. (4) hydraulic coke. (5) coke dehydration and storage. (6) blow-off and venting system. (7) steam-generating  (8) coke roasting . the furnace outlet temperature is set to 495-500 ℃, coke tower pressure is set to 0.15-0.2 Mpa.

Low carbon hydroxyl synthetic core technology is adopted in rhodium catalysts, thus the reaction pressure is reduced greatly. Therefore, the factory investment and maintenance cost is low, propylene generating butanol of high selectivity, reaction velocity is fast, product yield is high, raw material consumption is little, catalyst is little, easy operation, corrosive small, less contamination of environment (nearly harmless technology). Therefore, this method of production worldwide with distinct advantage and rapid development, it is the main methodes of  butyl alcohol and octyl alcohol now.

benzole scrubber and ammonia distillation tower

butyl alcohol by gas hydrogenation evaporator tower and octyl alcohol by gas hydrogenation evaporator tower

ammonia-containing coking wastewater  processing system process schematic

Loading tower for shipping





coking/delayed coking butyl-octyl alcohol factory

polysilicon/methyl alcohol tower manufacturing

The Poly crystalline silicon is the raw material of mono crystalline production, it is the electronic information base material of semiconductor devices such as contemporary artificial intelligence, automatic control, information processing, photoelectric conversion . It's called "the foot stone of microelectronics ".

In the solar energy utilization, mono crystalline silicon and poly crystalline also plays a tremendous role. Although from the fact that will make solar power has large market, and accept by vast consumers , we must improve the solar photoelectric conversion efficiency, reduce production cost. From the current international solar cell development process,it can see the development trends of mono crystalline silicon, poly silicon, ribbon silicon ,thin film materials (including micro crystalline silicon base film, compound base film and dye film).


Low-temperature methanol washing process use the cold methanol as solvent, and the excellent characteristics of  methanol absorbing acidic gas at low temperature , removing the acidic gas gas from raw material gas.
This process is with high degree of the gas purification and  good selectivity, the gas depressurization and decarbonlization can be procesed selectively in the same tower in subsection.

Low-temperature methanol washing process technology is mature and it has a good application performance in industry, it has been used extensively in synthetic ammonia, synthesis methanol and other hydrology synthesis, city gas, industrial hydrogen production and gas desulfurization etc gas purification devices. this technology is used in the large ammonia plant with coal and residue as raw material in domestic.

The following poly silicon/methyl alcohol tower devices are designed and manufactured by Wuhan XinFa Petrifaction Equipment Co., Ltd.

tower design graph

From left to right are Hydrogen absorbing tower, Hydrogen resolving  tower,circulating chlorosilane rectifying tower, methyl alcohol washing tower, methyl alcohol regenerating tower

Hydrogen absorbing tower

Hydrogen resolving  tower

methyl alcohol regenerating tower

Chlor-Alkali converter equipment

The converter is the key equipment in the in chlor-alkali production ,the converter is made by Wuhan XinFa Petrochemical Equipment Co., Ltd that has nice sealing effect as well as working life long.

With scientific processing technology, superb production technology and strict quality guarantee system, our company ensure every one of heat exchange tube and tube plate perfect union, flawless, durable. Adopt before welding welding parts with surrounding acetone cleaning, polishing and grinding collection scope face to metallic luster. Comprehensive automatic tube plate argon arc welding again from melting, twice wire filling welding and ultrahigh pressure pipe liquid bulging bag twice the tube expanding, shading and long time pressure-keeping tightness test, the entire many-side damping transportation measures, to ensure the high standard requirement of the converter for customers.

The following photos are the converters we designed and produced for our Chlor-Alkali plant customer.

converter design diagram

DN2800mm after converter

DN3000mm former converter

DN3200mm former converter

Converters we produced

Loading converters

Chlor-Alkali plant
